KL4010T

KL4010T

KL4010T
4000kg
Rated Load
10300kg
Operating Weight

KL4010T

none

No Image

Key Features

KL4010T SIDE

Technical Data

4000kg
Rated Load
10300kg
Operating Weight
Max Power85 kW
Max Reach6100 mm
Tire Type400/70-24
Wheelbase3150 mm
Drive Mode4WD
Rated Load4000 kg
Fork Length1220 mm
Engine ModelYCD4J22T Tier II
Cooling MethodWater Cooling
Ground Clearance350 mm
Max Gradeability≤50%
Max Travel Speed35 km/h
Operating Weight10300 kg
Fuel Tank Capacity195 L
Max Lifting Height10600 mm
Overall Dimensions7000×2200×2550 mm
Cab Safety StandardFOPS
Hydraulic Tank Capacity170 L

Attachments

360° Rotating Grapple

360° Rotating Grapple

Forklift Forks with Upper Tines

Forklift Forks with Upper Tines

Forks with Three Upper Tines

Forks with Three Upper Tines

High-Dump Grain Bucket

High-Dump Grain Bucket

Bucket

Bucket

Snow Blower

Snow Blower
